설정 up a compact HDMI adapter is straightforward, but following the correct order ensures a smooth first 연결. This 가이드 walks you through each step.

What You Need

• Nintendo Switch (any model)
• Compact HDMI adapter
• HDMI 케이블
• TV or 모니터
• USB-C charger (official Nintendo adapter or 15V/2.6A+ PD charger)

Step 1: Connect the Adapter to the Switch

With the Switch powered off, insert the compact HDMI adapter firmly into the USB-C port on the bottom of the 콘솔. Make sure it goes all the way in — a loose 연결 is the most common cause of 디스플레이 issues.

Step 2: Connect the HDMI 케이블

Plug one end of the HDMI 케이블 into the adapter’s HDMI port and the other end into your TV or 모니터. Turn on the 디스플레이 and select the correct HDMI input source.

Step 3: Connect the Power

Plug your USB-C charger into the adapter’s power input port. This is essential — the Switch cannot output video in TV mode without external power. Using a 스마트폰 charger (typically 5V/2A) will not provide enough power. Use the official Switch AC adapter or a PD charger rated for 15V/2.6A or higher.

Step 4: Power On and Verify

Turn on your Switch. The TV should 디스플레이 the home 화면 within a few seconds. If nothing appears:

• Check that the HDMI 케이블 is fully inserted at both ends
• Verify the TV input source matches the HDMI port you used
• Confirm the charger is supplying power (look for the 충전 indicator on the Switch)

Step 5: Test and Play

Launch a game and verify the video and audio output. If the 화면 flickers or the audio cuts out, try a different HDMI 케이블. Shorter cables (under 6 feet) tend to produce more stable signals.

Summary

Setup is simple: insert the adapter, connect HDMI and power, and you are ready to play. Most 연결 problems are caused by insufficient power or loose cables. Use a proper PD charger and make sure everything is firmly connected.
